GPFS Parallel File System Explained
What is GPFS?
IBM Spectrum Scale, formerly the General Parallel File System (GPFS) is high-performance clustered file system software developed by IBM in 1998. It was originally designed to support high-streaming applications in the media and entertainment space. It can be deployed in shared-disk or shared-nothing distributed parallel modes, or a combination of these two. The predominant deployment is as a shared-disk solution utilizing SAN block storage for persistent storage.
Advantages of a Modern Parallel File System over GPFS
Although IBM Spectrum Scale (aka IBM GPFS) is a parallel file system, it was developed over 20 years ago to support the high throughput needs of multimedia applications. And for the subsequent 15+ years it was optimized to deliver the highest large file bandwidth performance from hard disk drives. But the world has changed dramatically in the last ten years, flash technology has revolutionized the data center and workloads have changed from large sequential to metadata intensive small File I/O intensive big data workloads. The technology designed and fine-tuned to solve streaming applications is not suitable for the age of big data and analytics. IBM continues to develop its Spectrum Scale product, yet the file system still can not deliver performance for small file, low latency, I/O intensive workloads.
A modern parallel file system leverages new technologies such as NVMe, high speed low latency networking to service small file I/O in a massively parallel manner. In addition to managing small files efficiently, the metadata demands for AI and GPU workloads is orders of magnitude higher. A modern parallel file system utilizes a distributed metadata model where metadata is spread evenly across all the storage nodes and each node contains equal amounts of data and metadata. By contrast, the traditional GPFS model maintains metadata in separate metadata servers. This creates a performance bottleneck when the system contains millions of files.
Advantages of modern file systems
- Best choice for GPU workloads which contain millions of files, large and small
- Full featured, Easy to use, easy to manage, no need for specialized administrators to configure, manage and tune the storage system
- High throughput, high IOPS, with ultra-low latency, fully saturating the network and delivering applications linear performance at exabyte scale, especially for mixed workloads
GPFS vs. Modern Parallel File System (WEKA)
| Hardware | Spectrum Scale (on ESS 3000) | WEKA (COTS Hardware) |
| Server Nodes per Chassis | 1 in 2 RU, Custom | 1 in 1RU or 4 in 2RU, COTS |
| # of Server Nodes | 1 to Thousands | 6 to Thousands |
| Server Generation | Intel Skylake | Intel Cascade Lake Refresh, AMD EPYC |
| Memory per Node | 768GB | 192GB, 6 channels |
| SSD Interface | NVMe (still has SAS/SATA baggage) | Natively NVMe |
| Front-End Network | Up to 100G | Up to 200Gb |
| NVMe over Fabric | Requires 3rd-Party Add-On | Native |
| Protocol Support | ||
| POSIX | Yes | Yes |
| GPUDirect | No | Yes |
| NFS | Yes | Yes |
| SMB | Yes | Yes, SMB 2/3 |
| HDFS | Yes | Not Required: Mount from POSIX |
| S3 | Yes | Yes |
| Performance1 | ||
| Read Throughput1,2 | 40GB/s | 56GB/s |
| Write Throughput1,2 | 32GB/s | 20GB/s |
| Read IOPS1 | No Data from Vendor | 5.8M |
| Write IOPS1 | No Data from Vendor | 1.6M |
| Single Mount Point, Full Coherency | No Data from Vendor | 82GB/s |
| #1 on IO500 and SPEC | No | Yes |
1 At smallest cluster configuration
2 Spectrum Scale on ESS 3000, performance will vary on other hardware
Feature Comparison: GPFS vs. Parallel File System (WEKA)
| Feature | Spectrum Scale (on ESS 3000) | WEKA |
| Ease of Use | Hard | Easy |
| Snapshots | Yes, with Performance Impact | Yes – Instantaneous |
| Snapshot-to-Object Store/S3 | No | Yes |
| Tiering/Hybrid Disk Storage | No, Tiering Impacts Performance | Yes |
| Independent Cap/Perf Scaling | No | Yes |
| Thousands of Nodes | Yes | Yes |
| Dynamic Performance Scaling | No | Yes |
| Encryption | In-Flight and At-Rest | In-Flight and At-Rest |
| Replication | Yes | Yes (via Snapshot) |
| Data Protection | N+3, Reed Solomon EC only on ESS Appliance | N+4 Distributed Data Protection with High Performance EC |
| Compression/Deduplication | Limited/No | Future Release |
| S/W Only, H/W Independent | Yes | Yes |
| End-to-End Checksum | No | Yes |
| Active Directory and LDAPP Authentication | Yes | Yes |
| Compression/Deduplication | Limited/No | Future Release |
| S3 | via Swfi | Yes |
| SMB | Limited/No | Yes, SMB 2/3 |
| User Quotas | Yes | Yes |
| Authenticated Mounts | Yes | Yes |
| High Availability Bonding | Yes | Yes |
| IB Support (Ideal for GPUs) | Yes | Yes |
Learn how WEKA’s file system delivers the highest performance for the most data-intensive workloads.
